Manufacturer

GAC Aian New Energy

level

Compact SUV

Energy type

pure electric

time to market

2023.03

electric motor

Pure electric 136 horsepower

Pure electric cruising range (km) Ministry of Industry and Information Technology

430

Pure electric cruising range (km) CLTC

430

Charging time (hours)

Fast charging capacity(%)

Maximum power(kW)

100(136Ps)

Maximum torque (N·m)

176

gearbox

Electric vehicle single speed gearbox

Length x width x height (mm)

4535x1870x1650

body structure

5-door, 5-seater SUV

Maximum speed (km/h)

150

Official acceleration time to 100 kilometers (s)

Electricity consumption per 100 kilometers (kWh/100km)

12.9kWh

Electric energy equivalent fuel consumption (L/100km)

1.46

Vehicle warranty period

4 years or 150,000 kilometers

Estimated total maintenance cost for 60,000 kilometers

233.0 yuan

Body

Length(mm)

4535

Width(mm)

1870

Height (mm)

1650

Wheelbase(mm)

2750

Front wheelbase (mm)

1600

Rear wheelbase (mm)

1600

Minimum ground clearance (mm)

150

body structure

SUV

Number of doors (number)

5

Car door opening method

swing door

Number of seats (seats)

5

Curb weight (kg)

1635

Full load mass (kg)

2180

Luggage compartment volume (L)

405

Minimum turning radius

5.5m

electric motor

Motor description

Pure electric 136 horsepower

Motor type

Permanent magnet/synchronous

Total motor power (kW)

100

Total motor horsepower (Ps)

136

Total torque of motor (N·m)

176

Maximum power of front electric motor (kW)

100

Maximum torque of front electric motor (N·m)

176

Number of drive motors

single motor

Motor layout

prefix

Battery/Charging

Battery Type

Lithium iron phosphate battery

Battery Features Technology

magazine battery

Battery brand

Yiwei Power

Battery pack warranty

Lifetime warranty for the first owner (the liability exemption clause shall be subject to the official)

Battery capacity (kWh)

51.9

Battery energy density (Wh/kg)

Battery charging rate

battery charging

●Fast charging interface

Fast charging interface location

left fender

Slow charging interface location

Right fender

Battery temperature management system

●Low temperature heating

●liquid cooling

Single pedal mode

●Standard configuration

VTOL mobile power station functions

○Optional1000 yuan

VTOL maximum external discharge power

VTOV maximum external discharge power

gearbox

Gearbox description

Electric vehicle single speed gearbox

Number of gears

1

Gearbox type

fixed ratio gearbox

Chassis/steering

Drive mode

Front wheel drive

front suspension form

MacPherson independent suspension

Rear suspension form

Trailing arm torsion beam non-independent suspension

steering type

electric assist

Body structure

Load-bearing

wheels/brakes

Front brake type

ventilated disc

rear brake type

solid disc

Parking brake type

Electronic parking

Front tire size

215/55 R17

Rear tire size

215/55 R17

Spare tire specifications

○Not full size1000 yuan

Spare tire placement

○Hidden

active safety●Standard configuration○Optionalnone

ABS anti-lock

●Standard configuration

Braking force distribution (EBD/CBC, etc.)

●Standard configuration

Brake assist (EBA/BA, etc.)

●Standard configuration

Traction control (TCS/ASR, etc.)

●Standard configuration

Body stability system (ESP/DSC, etc.)

●Standard configuration

Active safety warning system

Active braking

Parallel assistance

Lane Keeping Assist System

Lane centering

Fatigue driving tips

Active DMS fatigue testing

In-car vital signs detection

Road traffic sign recognition

Traffic light identification

night vision system

passive safety●Standard configuration○Optionalnone

front airbag

●Driver's seat

●Passenger seat

side airbag

side curtain airbags

Front knee airbag

center airbag

Seat belt not fastened reminder

●Standard configuration

tire pressure monitoring system

●tire pressure alarm

Child seat interface (ISOFIX)

●Standard configuration

passive pedestrian protection

safety tires

Auxiliary/control configuration●Standard configuration○Optionalnone

parking radar

●back

Warning when the vehicle ahead is leaving

Driving assistance images

●Reversing imageIllustration

cruise system

●cruise controlIllustration

Automatic lane change assist

Automatic ramp exit (entry)

Navigation assisted driving

Assisted driving level

Automatic parking

Follow the trail and reverse

memory parking

Automatic parking (AUTOHOLD)

●Standard configuration

Hill Ascent Assist (HAC)

●Standard configuration

Hill Descent (HDC)

Variable suspension adjustment

air suspension

Electromagnetic induction suspension

variable steering ratio system

Front axle limited slip mode

Rear axle limited slip mode

Center differential locking function

low speed four wheel drive

Integral active steering system

Driving mode selection

●sports

●ECO/Economy

●Standard comfort

brake energy recovery system

●Standard configuration

Low speed driving warning sound

●Standard configuration

External configuration●Standard configuration○Optionalnone

Skylight type

Light-sensing awning

roof rack

●Standard configuration

Sport appearance package

Electric spoiler

Active closing air intake grille

Aluminum alloy wheels

○Optional

car side pedals

Frameless design door

Hidden door handle

●Standard configuration

tow hitch

Internal configuration●Standard configuration○Optionalnone

Steering wheel material

●cortex

steering wheel adjustment

●up and down

Electric steering wheel adjustment

Steering wheel functions

●Multifunctional control

Shift pattern

●electronic handrail

Driving computer screen

●color

LCD instrument style

●All LCD

LCD meter size (inches)

●10.25

Comfort/anti-theft configuration●Standard configuration○Optionalnone

Electric suction door

Electric tailgate

Sensing rear tailgate

Electric rear tailgate position memory

Central locking in car

●Standard configuration

Remote key type

●Smart remote key

keyless entry

●front row

Keyless start

●Standard configuration

remote start

●Standard configuration

remote control mobile vehicle

Vehicle summoning function

Heads-up Display System (HUD)

Built-in driving recorder

Original ETC

○Optional200 yuan

Active noise reduction

Mobile phone wireless charging

110V/220V/230V power socket

Luggage compartment 12V power interface

Seat configuration●Standard configuration○Optionalnone

seat material

●fabric

Sports style seats

Seat layout

●2+3

Second row independent seats

third row seats

Seat electric adjustment

Overall adjustment of driver's seat

●Move forward and backward

●Backrest angle

●Height adjustment

Driver's seat partial adjustment

●headrest

Overall adjustment of passenger seat

●Move forward and backward

●Backrest angle

Passenger seat partial adjustment

●headrest

Second row seat overall adjustment

Partial adjustment of second row seats

Front seat functions

Second row seat functions

Third row seat functions

Boss button

Front/rear armrests

●front row

Rear cup holder

Heated/cooled cup holder

Front seats fold flat

●Standard configuration

Rear seat folding ratio

●40:60

Electrically reclining rear seats

Second row small table

Intelligent Internet●Standard configuration○Optionalnone

Central control screen size (inches)

●14.6

Central control screen material

satellite navigation system

●Standard configuration

AR real-life navigation

Navigation traffic information display

●Standard configuration

roadside assistance service

●Standard configuration

Bluetooth/car phone

●Standard configuration

Mobile Internet Mapping

Internet of Vehicles

●Standard configuration

4G/5G network

●4G

OTA upgrade

●Standard configuration

facial recognition

Fingerprint recognition

Voiceprint recognition

emotion recognition

Voice recognition control system

●Standard configuration

Voice wake-up-free function

Voice area wake-up recognition function

●main driver

●co-pilot

continuous speech recognition

●Standard configuration

It can be said that it is visible

●Standard configuration

Voice assistant wake word

Hello Beibi

Gesture control function

Wi-Fi hotspot

●Standard configuration

Audiovisual entertainment●Standard configuration○Optionalnone

Multi-finger flying screen control

app store

●Standard configuration

multimedia interface

●USB/Type-C

Number of USB/Type-C interfaces

●1 person in the front row

●1 in the back row

USB/Type-C maximum charging power

car tv

rear LCD screen

simulated sound

Karaoke function

●Standard configuration

audio brand

Number of speakers (pieces)

●6

Rear multimedia control

Lighting configuration●Standard configuration○Optionalnone

Low beam

●LED

High beam

●LED

daytime running lights

●Standard configuration

Adaptive high and low beam

automatic headlights

●Standard configuration

Turn assist light

front fog lights

Headlight adaptive steering (AFS)

Headlight height adjustment

●Standard configuration

Headlight cleaning function

Car interior ambient light

Active ambient lighting

Lighting features

Light projection technology

Delayed turn off of headlights

●Standard configuration

Headlight rain and fog mode

glass/rear view mirror●Standard configuration○Optionalnone

electric windows

●front row

●back row

One-click lifting and lowering of windows

●whole car

Window anti-pinch function

●Standard configuration
